Главная Каталог продукции Toolunited 17 303-08 - Rounded profile end mill, concave MM ER2.0/078-6.0-4T06 IC908

MM ER2.0/078-6.0-4T06 IC908

MM ER2.0/078-6.0-4T06 IC908

MM ER2.0/078-6.0-4T06 IC908

Iscar
Артикул: 5667827
В наличии
В корзину
Описание
Характеристики
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
5.9944 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
10.0076 mm
Delivery state valid from
6/1/2017
DIN
SAI00600105
DN Neck diameter
10.0076 mm
FamilyProducts
Interchageable 4 flute solid carbide corner rounding milling heads.
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDMFG Grade manufacturers designation
IC908
HAND Cutting direction
R - Right
ID Technical product number
5667827
Interface codes
J6 / J61
ISO
SAI01F6000$$$$
ISYC Subclass
303-08 - Rounded profile end mill, concave
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAI Screw mounting ISCAR
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0060
LOC-03 ISO
SAI01F6000$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAI00600105
LPR Protruding length
13.0048 mm
Name Identifying order number
MM ER2.0/078-6.0-4T06 IC908
PRFRAD Profile radius 1
2.0066 mm
Working process
FEC - Square shoulder milling
ZEFP Peripheral effective cutting edge count
4
