T846NPT03750-18R-A KSU30

Артикул: 5629710

В наличии

В корзину

Описание

Характеристики

BMC Body material code

S - Solid steel

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

bright

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

Delivery state valid from

3/2/2016

DIN

ZYL07002125

FamilyProducts

T846, NPT, Standard Chamfer, Standard Projection

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GRDMFG Grade manufacturers designation

KSU30

GRDPRIO Standard designation of the grade main application

HSS-E

HAND Cutting direction

R - Right

ID Technical product number

5629710

Interface codes

J6 /

ISYC Subclass

301-00 - Thread cutting tap, forming tap, cutting die unspecified

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

2 Inch

LOC-03 CZCMS Connection size code

0700

LOC-03 DCONMS Diameter

17.78 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL07002125

Materials

P,K

Name Identifying order number

T846NPT03750-18R-A KSU30

NOF Flute count

OAL Overall length

65.024 mm

TDFR Thread diameter nominal fraction

3/8 in

TDIN Thread diameter nominal inch

0.375 in

TG Taper ratio

1:16

THFT Thread form type

NPT

THL Thread cutting part length

26.162 mm

TPI Threads per inch

18 1/in

TTPID Tap type identifier

6 - Special tap

Working process

BG - Tapping
