Главная Каталог продукции Toolunited 17 312-01 - Cylindrical reamer PM11B-04800-25N1

PM11B-04800-25N1

Артикул: 02503708

В наличии

В корзину

Описание

Характеристики

COMPC Company code

SO - SECO Tools

DC Cutting diameter minimum

21.5 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter 1st step maximum

26.499 mm

Delivery state valid from

3/14/2020

DIN

ZYL02500105

FamilyProducts

PM11B-04800-25N1

HAND Cutting direction

R - Right

ID Technical product number

02503708

Interface codes

J6 / J61

ISO

ZYL01G2500h$06

ISYC Subclass

312-01 - Cylindrical reamer

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0250

LOC-03 DCONMS Diameter

25 mm

LOC-03 ISO

ZYL01G2500h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02500105

LS Shank length

56 mm

LU Usable length

45 mm

Name Identifying order number

PM11B-04800-25N1

OAL Overall length

107 mm

Working process

No working processes available

WT Weight of item

0.256 kg
