PF84-25H6-EN1

Артикул: 02602349

В наличии

В корзину

Описание

Характеристики

COMPC Company code

SO - SECO Tools

DC Cutting diameter minimum

25 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

6/7/2017

DIN

SO-SO PM11

FamilyProducts

PF84-25H6-EN1

HAND Cutting direction

R - Right

ID Technical product number

02602349

Interface codes

J6 /

ISYC Subclass

312-01 - Cylindrical reamer

LF Functional length

20 mm

LOC-03 CZCMS Connection size code

0110

LOC-03 DCONMS Diameter

11 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SO-SO PM11

MIID Master insert identification outside cutting edge 1st step

LNEG1003-EN1...

Name Identifying order number

PF84-25H6-EN1

Working process

No working processes available

WT Weight of item

0.1 kg
