Главная Каталог продукции Toolunited 17 309-10 - System tool for internal threading GL50-CNL-32035-9-I

GL50-CNL-32035-9-I

GL50-CNL-32035-9-I GL50-CNL-32035-9-I GL50-CNL-32035-9-I GL50-CNL-32035-9-I

GL50-CNL-32035-9-I

Seco
Артикул: 03011856
В наличии
В корзину
Описание
Характеристики
BDRED Body diameter reduced
50 mm
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
GRL05000115
DMIN Minimum bore diameter
63 mm
FamilyProducts
GL50-CNL-32035-9-I
HAND Cutting direction
L - Left
HF Functional height
0 mm
ID Technical product number
03011856
Interface codes
J6 /
ISYC Subclass
309-10 - System tool for internal threading
LF Functional length
35 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
GRL GRANLUND
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
GRL05000115
LPR Protruding length
35 mm
LTA Length tool assembly
35 mm
MTP Clamping type code
C - Top clamping without bore
Name Identifying order number
GL50-CNL-32035-9-I
WF Functional width
32 mm
Working process
No working processes available
WT Weight of item
0.392 kg
