Главная Каталог продукции Toolunited 17 308-06 - Half-side slot milling cutter FST D6.0-0.50-12-R10

FST D6.0-0.50-12-R10

FST D6.0-0.50-12-R10 FST D6.0-0.50-12-R10

FST D6.0-0.50-12-R10

Iscar
Артикул: 3100882
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A2A Clearance angle major Pos. A
11 Degree
B1A Cutting edge length Pos. A
10.2 mm
B3A Inscribed circle diameter Pos. A
10.2 mm
BLDA Tool style code Position A
2
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
4.12 mm
CCONMS Connection count machine side
2
CDX Cutting depth maximum
42.672 mm
CICT Cutting item count
14
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
0 - Without coolant exit
D1A Corner radius Pos. A
0.6 mm
DC Cutting diameter
152.4 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
7/7/2017
DHUB Hub diameter
80.01 mm
DIN
FDA15000220
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
14
FamilyProducts
Top-Side Cutting, Flanged Type Slotting Cutters
HAND Cutting direction
R - Right
ID Technical product number
3100882
Interface codes
J6 / J61
ISO
FDA02G3810H$07
ISYC Subclass
308-06 - Half-side slot milling cutter
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1500
LOC-03 DCONMS Diameter
38.1 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
H$07
LOC-03 ISO
FDA02G3810H$07
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA15000220
Name Identifying order number
FST D6.0-0.50-12-R10
OAL Overall length
57.15 mm
TCDCONMS ISO-tolerance class shank diameter
H7
Working process
FNU - Groove milling
WT Weight of item
117.602 kg
ZEFF Face effective cutting edge count
14
ZEFP Peripheral effective cutting edge count
14
