Главная Каталог продукции Toolunited 17 308-05 - Full-side slot milling cutter R335.15-02.50-18

R335.15-02.50-18

R335.15-02.50-18 R335.15-02.50-18 R335.15-02.50-18 R335.15-02.50-18

R335.15-02.50-18

Seco
Артикул: 75072222
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
5.5 mm
CICT Cutting item count
10
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CWN Cutting width minimum
5.15 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
63.5 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
39.9 mm
DIN
FDA07502220
FamilyProducts
R335.15-02.50-18
GAMF Rake angle radial
0 Degree
GAMP Rake angle axial
0 Degree
HAND Cutting direction
R - Right
ID Technical product number
75072222
Interface codes
J6 /
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
SO-335 1518N
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0750
LOC-03 DCONMS Diameter
19.05 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA07502220
Name Identifying order number
R335.15-02.50-18
OAL Overall length
39.9 mm
RPMX Rotational speed maximum
17300 1/min
Working process
No working processes available
WT Weight of item
0.469 kg
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
