Главная Каталог продукции Toolunited 17 308-05 - Full-side slot milling cutter FDN D5.0-0.62-10-XN13

FDN D5.0-0.62-10-XN13

FDN D5.0-0.62-10-XN13

FDN D5.0-0.62-10-XN13

Iscar
Артикул: 3106746
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A1B Cutting edge angle major Pos. B
90 Degree
A2A Clearance angle major Pos. A
0 Degree
A2B Clearance angle major Pos. B
0 Degree
B1A Cutting edge length Pos. A
13 mm
B1B Cutting edge length Pos. B
13 mm
B3A Inscribed circle diameter Pos. A
13 mm
B3B Inscribed circle diameter Pos. B
13 mm
BLDA Tool style code Position A
2
BLDB Tool style code Position B
2
BMC Body material code
S - Solid steel
C1A Insert thickness Pos. A
8.8 mm
C1B Insert thickness Pos. B
8.8 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
35.0012 mm
CICT Cutting item count
12
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
0 - Without coolant exit
D1A Corner radius Pos. A
0.8 mm
D1B Corner radius Pos. B
0.8 mm
DC Cutting diameter
127 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
7/7/2017
DHUB Hub diameter
65.024 mm
DIN
FDA12501220
FamilyProducts
Full Slot Flange Type Slotting Cutters Carrying XNMU 1306 Square Inserts with 4
HAND Cutting direction
R - Right
ID Technical product number
3106746
Interface codes
J6 /
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
XNMU 130608PNTN
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
IS-XN1306083N
LOC-03 CCFMS Connection code form
12
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1250
LOC-03 DCONMS Diameter
31.75 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
H$07
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA12501220
Name Identifying order number
FDN D5.0-0.62-10-XN13
OAL Overall length
50.8 mm
TCDCONMS ISO-tolerance class shank diameter
H7
Working process
No working processes available
WT Weight of item
68.072 kg
ZEFF Face effective cutting edge count
6
ZEFP Peripheral effective cutting edge count
6
