335.25-315.2632XL.60-9N

335.25-315.2632XL.60-9N 335.25-315.2632XL.60-9N 335.25-315.2632XL.60-9N 335.25-315.2632XL.60-9N

335.25-315.2632XL.60-9N

Seco
Артикул: 02827449
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
113.3 mm
CICT Cutting item count
27
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CWN Cutting width minimum
26 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
315 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
84 mm
DIN
FDA06002100
FamilyProducts
335.25-315.2632XL.60-9N
GAMF Rake angle radial
-8 Degree
GAMP Rake angle axial
-5 Degree
HAND Cutting direction
N - Neutral
ID Technical product number
02827449
Interface codes
J6 /
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
SO-LN1707 3N
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0600
LOC-03 DCONMS Diameter
60 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA06002100
Name Identifying order number
335.25-315.2632XL.60-9N
OAL Overall length
32 mm
RPMX Rotational speed maximum
3300 1/min
Working process
No working processes available
WT Weight of item
12.254 kg
ZEFF Face effective cutting edge count
9
ZEFP Peripheral effective cutting edge count
9
