Главная Каталог продукции Toolunited 17 308-05 - Full-side slot milling cutter 335.18-04.00-0506N-R4

335.18-04.00-0506N-R4

335.18-04.00-0506N-R4 335.18-04.00-0506N-R4 335.18-04.00-0506N-R4 335.18-04.00-0506N-R4

335.18-04.00-0506N-R4

Seco
Артикул: 02834707
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
29 mm
CICT Cutting item count
12
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CWN Cutting width minimum
8 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
103.6 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
39.4 mm
DIN
FDA10002120
FamilyProducts
335.18-04.00-0506N-R4
GAMF Rake angle radial
-4 Degree
GAMP Rake angle axial
0 Degree
HAND Cutting direction
N - Neutral
ID Technical product number
02834707
Interface codes
J6 /
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
SO-RD0803 3N
LOC-03 CCFMS Connection code form
21
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1000
LOC-03 DCONMS Diameter
25.4 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA10002120
Name Identifying order number
335.18-04.00-0506N-R4
OAL Overall length
15.875 mm
RPMX Rotational speed maximum
9400 1/min
Working process
No working processes available
WT Weight of item
0.358 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
