Главная Каталог продукции Toolunited 17 309-02 - Turning tool for external threading SWL4040S22

SWL4040S22

SWL4040S22 SWL4040S22 SWL4040S22

SWL4040S22

ZCC Cutting Tools
Артикул: SWL4040S22
В наличии
В корзину
Описание
Характеристики
CEDC Cutting edge count
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
ZCC - ZCC Cutting Tools
CXSC Coolant exit style code
0 - Without coolant exit
DCP Data chip provision
0 - Without data chip
Delivery state
SF - Made to order
DIN
VKT40400105
DIN CSW1
ZCC-LT22.01W
FamilyProducts
Threading tool holder (external)
HAND Cutting direction
L - Left
HF Functional height
40 mm
ID Identifying order number
SWL4040S22
Interface codes
J6 /
Interface codes CSW1
J41 /
ISYC Subclass
309-02 - Turning tool for external threading
LF Functional length
250 mm
LOC-03 B Shank width
40 mm
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
VKT Square mounting
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
4040
LOC-03 H Shank height
40 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
VKT40400105
MTP Clamping type code
S - Screwed across bore with, counter bore
OAL Overall length
250 mm
STDDES Standard designation
SWL4040S22
SX Shank cross section shape code
01 - Square shank
THSC Tool holder shape code
A - offset shank design
Working process
DGA - Thread turning, external
