Главная Каталог продукции Toolunited 17 306-01 - Twist drill for indexable inserts DFSP250R5WB25M

DFSP250R5WB25M

DFSP250R5WB25M

DFSP250R5WB25M

Kennametal
Артикул: 6080194
В наличии
В корзину
Описание
Характеристики
A1B Cutting edge angle major Pos. B
90 Degree
A2B Clearance angle major Pos. B
11 Degree
BLDA Tool style code Position A
7
BLDB Tool style code Position B
2
CCONMS Connection count machine side
1
CEDC Cutting edge count
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1B Corner radius Pos. B
0.8 mm
DC Cutting diameter minimum
25 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/28/2017
DIN
ZYL02501015
FamilyProducts
Drill Fix DFSP drill, Weldon shank, 5 x D, metric
HAND Cutting direction
R - Right
ID Technical product number
6080194
Interface codes
J6 /
ISYC Subclass
306-01 - Twist drill for indexable inserts
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0250
LOC-03 DCONMS Diameter
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02501015
LS Shank length
56 mm
LU Usable length
125 mm
Name Identifying order number
DFSP250R5WB25M
NUMBER INSERTS INSIDE Number of inserts inside
1
NUMBER INSERTS OUTSIDE Number of inserts outside
1
OAL Overall length
158 mm
PL Point length
0.7 mm
Working process
BVB - Drilling
