XDKT 11T320SR-F50 CTP2235

Артикул: 11274500

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

F50

CECC Cutting edge condition code

S - Chamfered and rounded

COMPC Company code

CE - Ceratizit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

2.8 mm

DIN

XD11T3203R

FamilyProducts

milling insert XDKT-F50

GRD2ND Standard designation of the grade 2nd application

HC-M40

GRDMFG Grade manufacturers designation

CTP2235

GRDPRIO Standard designation of the grade main application

HC-P40

IC Inscribed circle diameter

6.8 mm

ID Technical product number

11274500

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-00 - Regular Insert unspecified

L Cutting edge length

10.6 mm

LE Cutting edge effective length

2.1 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

XD11T3203R

Name Identifying order number

XDKT 11T320SR-F50 CTP2235

RE Corner radius

2 mm

S Insert thickness

3.8 mm

S1 Insert thickness total

3.8 mm

STDDES Standard designation

XDKT11T320SR

TCINS Tolerance class insert

K - Cold formed

Working process

No working processes available
