Главная Каталог продукции Toolunited 17 201-05 - Parallelogram-shaped insert ADKT 1505PDSR-29 CTPM240

ADKT 1505PDSR-29 CTPM240

Артикул: 11898957

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

12 Degree

ANN Clearance angle minor

14 Degree

AS Clearance angle wiper edge

15 Degree

BS Wiper edge length

1.25 mm

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

S - Chamfered and rounded

COMPC Company code

CE - Ceratizit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

DIN

AD1505PD3R

EPSR Insert included angle

85 Degree

FamilyProducts

carbide milling insert

GRD2ND Standard designation of the grade 2nd application

HC-M40

GRDMFG Grade manufacturers designation

CTPM240

GRDPRIO Standard designation of the grade main application

HC-P40

IC Inscribed circle diameter

9.57 mm

ID Technical product number

11898957

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-05 - Parallelogram-shaped insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

15.2 mm

LE Cutting edge effective length

1.3 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

AD1505PD3R

Name Identifying order number

ADKT 1505PDSR-29 CTPM240

RE Corner radius

0.8 mm

S Insert thickness

5.65 mm

S1 Insert thickness total

5.65 mm

STDDES Standard designation

ADKT1505PDSR

TCINS Tolerance class insert

K - Cold formed

W1 Insert width

9.57 mm

Working process

No working processes available
