RNGN060300S-01525-LF CBN160C

RNGN060300S-01525-LF CBN160C RNGN060300S-01525-LF CBN160C RNGN060300S-01525-LF CBN160C

RNGN060300S-01525-LF CBN160C

Seco
Артикул: 02583483
В наличии
В корзину
Описание
Характеристики
AN Clearance angle major
0 Degree
CB Chip breaker face count
0 - Without chip breaker
CECC Cutting edge condition code
S - Chamfered and rounded
COMPC Company code
SO - SECO Tools
Delivery state valid from
3/14/2020
DIN
RN0603001N
FamilyProducts
RNGN060300S-01525-LF CBN160C
GRDMFG Grade manufacturers designation
CBN160C
IC Inscribed circle diameter
6.35 mm
ID Technical product number
02583483
IFS Insert mounting style code
1 - Without bore
IH Insert hand
N - Neutral
Interface codes
J6 / J441
ISISO ISO property
1
ISO
ISO$RN0603001NA$$00
ISYC Subclass
201-10 - Round insert
LOC-03 ISO
ISO$RN0603001NA$$00
LOC-03-Connection-codes
J6 / J441 - connection code machine end
LOC-03-DIN
RN0603001N
M M-dimension
6.35 mm
MIID Master insert identification
RNGN060300S CBN160C
Name Identifying order number
RNGN060300S-01525-LF CBN160C
NameAnsi Identifying order number inch alternative
RNGN22S-00625-LF CBN160C
S Insert thickness
3.18 mm
S1 Insert thickness total
3.18 mm
STDDES Standard designation
RNGN060300S
STDDESAnsi Standard designation ANSI
RNGN220S
TCINS Tolerance class insert
G
Working process
No working processes available
WT Weight of item
0.001 kg
