RFHN150400TLN KC710

Артикул: RFHN150400TLN KC710

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

25 Degree

BN Face land width

0.1 mm

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

Delivery state

LH - Stocked

DIN

KH-WP RFHN1504

FamilyProducts

ISO INSERT MILLING MCF45

GRDMFG Grade manufacturers designation

KC710

IC Inscribed circle diameter

15.9 mm

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-10 - Round insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KH-WP RFHN1504

M M-dimension

15.9 mm

Name Identifying order number

RFHN150400TLN KC710

STDDES Standard designation

RFHN150400TLN

STDDESAnsi Standard designation ANSI

RFHN530TLN

TCINS Tolerance class insert

Working process

No working processes available
