Главная Каталог продукции Toolunited 17 201-10 - Round insert RFCW150400ELN KC525M

RFCW150400ELN KC525M

Артикул: 1556644

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

25 Degree

BN Face land width

0.18 mm

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

5.5 mm

Delivery state valid from

1/4/2011

DIN

KH-WP RFCW1504

FamilyProducts

ISO INSERT MILLING RPF

GRDMFG Grade manufacturers designation

KC525M

IC Inscribed circle diameter

15.875 mm

ID Technical product number

1556644

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-10 - Round insert

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KH-WP RFCW1504

M M-dimension

15.875 mm

Name Identifying order number

RFCW150400ELN KC525M

S Insert thickness

4.76 mm

S1 Insert thickness total

4.76 mm

STDDES Standard designation

RFCW150400ELN

STDDESAnsi Standard designation ANSI

RFCW530ELN

TCINS Tolerance class insert

Working process

No working processes available
