Главная Каталог продукции Toolunited 17 201-09 - Octogonal insert OPGN060316 K68

OPGN060316 K68

Артикул: 1157412

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

11 Degree

CB Chip breaker face count

0 - Without chip breaker

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

Delivery state valid from

8/1/2008

DIN

KH-OPG524

EPSR Insert included angle

135 Degree

FamilyProducts

indexable insert for wheel and axle reconditioning

GRDMFG Grade manufacturers designation

K68

ID Technical product number

1157412

IFS Insert mounting style code

1 - Without bore

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-09 - Octogonal insert

L Cutting edge length

6.58 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KH-OPG524

Name Identifying order number

OPGN060316 K68

RE Corner radius

1.6 mm

S Insert thickness

3.18 mm

S1 Insert thickness total

3.18 mm

STDDES Standard designation

OPGN060316

TCINS Tolerance class insert

Working process

No working processes available
