Главная Каталог продукции Toolunited 17 201-09 - Octogonal insert ONMU 080608 SN-MK BCK20M

ONMU 080608 SN-MK BCK20M

Артикул: ONMU 080608 SN-MK BCK20M

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

0 Degree

CB Chip breaker face count

2 - With chip breaker on both sides

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

S - Chamfered and rounded

COATN Coating / Покрытие

PVD

COMPC Company code

BK - Boehlerit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

6.75 mm

Delivery state valid from

12/30/2016

DIN

ON0806083N

EPSR Insert included angle

135 Degree

FamilyProducts

indexable insert ONMU...-MK

GRD2ND Standard designation of the grade 2nd application

HC-N10

GRDMFG Grade manufacturers designation

BCK20M

GRDPRIO Standard designation of the grade main application

HC-P10

IC Inscribed circle diameter

19 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-09 - Octogonal insert

L Cutting edge length

8 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

ON0806083N

Name Identifying order number

ONMU 080608 SN-MK BCK20M

NOI Insert index count

RE Corner radius

0.8 mm

S Insert thickness

6.95 mm

S1 Insert thickness total

6.95 mm

STDDES Standard designation

ONMU080608SN

TCINS Tolerance class insert

Working process

FEC - Square shoulder milling,FPL - Face milling
