Главная Каталог продукции Toolunited 17 201-04 - Rectangular insert LDHT 15T3PDSR-29 CTPP235

LDHT 15T3PDSR-29 CTPP235

Артикул: 11883309

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

15 Degree

ANN Clearance angle minor

15 Degree

AS Clearance angle wiper edge

15 Degree

CB Chip breaker face count

1 - With chip breaker one-side

CBMD Chip breaker manufacturers designation

CECC Cutting edge condition code

S - Chamfered and rounded

COMPC Company code

CE - Ceratizit

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

4.4 mm

DIN

LD15T3PD4R

EPSR Insert included angle

88 Degree

FamilyProducts

carbide milling insert

GRD2ND Standard designation of the grade 2nd application

HC-M35

GRDMFG Grade manufacturers designation

CTPP235

GRDPRIO Standard designation of the grade main application

HC-P35

IC Inscribed circle diameter

9.52 mm

ID Technical product number

11883309

IFS Insert mounting style code

4 - Counter bore for screws with taper angle from 70° to 90°

IH Insert hand

R - Right

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-04 - Rectangular insert

KRINS Cutting edge angle major

90 Degree

L Cutting edge length

15 mm

LE Cutting edge effective length

1.2 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

LD15T3PD4R

Name Identifying order number

LDHT 15T3PDSR-29 CTPP235

RE Corner radius

0.8 mm

S Insert thickness

3.97 mm

S1 Insert thickness total

3.97 mm

STDDES Standard designation

LDHT15T3PDSR

TCINS Tolerance class insert

W1 Insert width

9.52 mm

Working process

No working processes available
