Главная Каталог продукции Toolunited 17 201-07 - Trigon insert DFT030204MD KC7845

DFT030204MD KC7845

Артикул: DFT030204MD KC7845

В наличии

В корзину

Описание

Характеристики

AN Clearance angle major

8 Degree

CBMD Chip breaker manufacturers designation

COMPC Company code

KH - Kennametal

CSP Coolant supply property

0 - Without coolant supply

D1 Fixing hole diameter

2.2 mm

Delivery state

LH - Stocked

DIN

KH-DFT0302

EPSR Insert included angle

84 Degree

FamilyProducts

DRILLING INSERT Form W

GRDMFG Grade manufacturers designation

KC7845

IC Inscribed circle diameter

6 mm

IFS Insert mounting style code

3 - Counter bore for screws with taper angle from 40° to 60°

IH Insert hand

N - Neutral

Interface codes

J6 /

ISISO ISO property

ISYC Subclass

201-07 - Trigon insert

L Cutting edge length

3.97 mm

LOC-03-Connection-codes

J6 / J441 - connection code machine end

LOC-03-DIN

KH-DFT0302

Name Identifying order number

DFT030204MD KC7845

RE Corner radius

0.4 mm

S Insert thickness

2.5 mm

S1 Insert thickness total

2.5 mm

Working process

BVB - Drilling
