Главная Каталог продукции Toolunited 17 405-08 - Cylindrical clamping sleeve 302155 10

302155 10

302155 10 302155 10 302155 10

302155 10

Hoffmann Group
Артикул: 302155 10
В наличии
В корзину
Описание
Характеристики
BD Body diameter
27 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
COATN Coating / Покрытие
0
COLST Collet slot type
2 - On two side
COMPC Company code
HOG - Hoffmann Group
CZCWS Connection size code
0100
DCB Connection bore diameter
10 mm
DCBN Connection bore diameter minimum
10 mm
DCBX Connection bore diameter maximum
10 mm
Delivery state valid from
1/11/2017
DFC Functional diameter
20 mm
DIN
ZYL02000115
FamilyProducts
Slotted reducing adapter
Interface codes
J6 /
ISYC Subclass
405-08 - Cylindrical clamping sleeve
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0100
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01000115
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000115
LSC Clamping length
32 mm
LSCX Clamping length maximum
32 mm
Name Identifying order number
302155 10
OAL Overall length
52.5 mm
SEALP Sealing
1 - With sealing
SZID Size identification
10
WT Weight of item
0.1 kg
