Главная Каталог продукции Toolunited 17 401-02 - Converter, stationary C4-RC2040-51030M

C4-RC2040-51030M

C4-RC2040-51030M C4-RC2040-51030M C4-RC2040-51030M C4-RC2040-51030M

C4-RC2040-51030M

Seco
Артикул: 75065642
В наличии
В корзину
Описание
Характеристики
BD Body diameter
40 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
CCS
CCUWS Connection code unit base
8
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0400
DCONWS Diameter
40 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
ZYV04000105
FamilyProducts
C4-RC2040-51030M
HAND Cutting direction
R - Right
HF Functional height
54 mm
ID Technical product number
75065642
Interface codes
J6 / J61
ISO
ZYV01G4000h$06
ISYC Subclass
401-02 - Converter, stationary
LB Body length 1
75 mm
LF Functional length
51 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
CCS Coromant Capto System SANDVIK
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0400
LOC-01 DCONWS Diameter
40 mm
LOC-01 ISO
CCS01C0400$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
CCS04000185
LOC-02 DCONWS Diameter
40 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
SO-CCS004001M0
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYV cylindrical shank VDI type (serrated)
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0400
LOC-03 ISO
ZYV01G4000h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYV04000105
LPR Protruding length
75 mm
Name Identifying order number
C4-RC2040-51030M
OAW Overall width
86 mm
WF Functional width
30 mm
WT Weight of item
3.798 kg
