Главная Каталог продукции Toolunited 17 401-00 - Adaptive item converter, extender, reducer unspecified E3471508516

E3471508516

Артикул: 00099664

В наличии

В корзину

Описание

Характеристики

BD Body diameter

56 mm

BLQ Balance quality code

CNSC Coolant entry style code

7 - Coolant entry, decentral and axially concentric

COMPC Company code

SO - SECO Tools

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

CZCWS Connection size code

0025

DCONWS Diameter

2.5 mm

DCONXWS Connection diameter max

16 mm

DCP Data chip provision

1 - With data chip

Delivery state valid from

3/14/2020

DIN

SKG05001795

FamilyProducts

E3471508516

HAND Cutting direction

N - Neutral

ID Technical product number

00099664

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LB Body length 1

93 mm

LF Functional length

112 mm

LOC-01 CZCWS Connection size code

0025

LOC-01 DCONWS Diameter

2.5 mm

LOC-01 DCONXWS Connection diameter max

16 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SKG steep taper shank

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SKG05001795

LPR Protruding length

112 mm

Name Identifying order number

E3471508516

OAL Overall length

213.7 mm

WT Weight of item

3.677 kg
