237655 HW63

Артикул: 237655 HW63

В наличии

В корзину

Описание

Характеристики

BD Body diameter

63 mm

CNSC Coolant entry style code

7 - Coolant entry, decentral and axially concentric

COMPC Company code

HOG - Hoffmann Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/11/2017

DF Flange diameter

63 mm

DIN

SKG04005795

FamilyProducts

Arbor

HAND Cutting direction

N - Neutral

Interface codes

J6 /

ISYC Subclass

401-00 - Adaptive item converter, extender, reducer unspecified

LF Functional length

64 mm

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

HOG-HW63

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SKG steep taper shank

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0400

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SKG04005795

LPR Protruding length

64 mm

Name Identifying order number

237655 HW63

OAL Overall length

129.4 mm

WT Weight of item

1.533 kg
