Главная Каталог продукции Toolunited 17 401-04 - Reducer, primary design KS-AD-HSK-C063-HSK-C032-050-01

KS-AD-HSK-C063-HSK-C032-050-01

KS-AD-HSK-C063-HSK-C032-050-01

KS-AD-HSK-C063-HSK-C032-050-01

Mapal
Артикул: 30319662
В наличии
В корзину
Описание
Характеристики
BD Body diameter
32 mm
BD Body diameter 2
37 mm
CCFWS Connection code form
03
CCSWS Connection code style
5
CCTWS Connection code type
HSK
CCUWS Connection code unit base
9
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
MP - Mapal
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0320
DCP Data chip provision
0 - Without data chip
DIN
HSK06300395
FamilyProducts
HSK reducing adapter
HAND Cutting direction
N - Neutral
ID Technical product number
30319662
Interface codes
J6 /
ISYC Subclass
401-04 - Reducer, primary design
LB Body length 1
30 mm
LOC-01 CCFWS Connection code form
03
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
HSK Hollow taper shank
LOC-01 CCUWS Connection code unit base
9 non-dimensional size with coolant
LOC-01 CZCWS Connection size code
0320
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
HSK03200395
LOC-03 CCFMS Connection code form
03
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03 DCONMS Diameter
63 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300395
LPR Protruding length
50 mm
Name Identifying order number
KS-AD-HSK-C063-HSK-C032-050-01
Rotation Rotation indicator
1 - rotating tool
WT Weight of item
0.7 kg
