Главная Каталог продукции Toolunited 17 401-04 - Reducer, primary design 335665 48/31

335665 48/31

335665 48/31 335665 48/31 335665 48/31

335665 48/31

Hoffmann Group
Артикул: 335665 48/31
В наличии
В корзину
Описание
Характеристики
BD Body diameter
68 mm
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SWB
CCUWS Connection code unit base
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0310
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/11/2017
DIN
SWB04800115
FamilyProducts
reducer
Interface codes
J6 /
ISYC Subclass
401-04 - Reducer, primary design
LB Body length 1
7 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SWB Quick change adapter BILZ
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0310
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SWB03100105
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
HOG-GEW2
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SWB Quick change adapter BILZ
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0480
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SWB04800115
LPR Protruding length
7 mm
Name Identifying order number
335665 48/31
