Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric SAH-2784950206

SAH-2784950206

SAH-2784950206 SAH-2784950206 SAH-2784950206 SAH-2784950206

SAH-2784950206

Seco
Артикул: 02836708
В наличии
В корзину
Описание
Характеристики
BD Body diameter
69.85 mm
CCFWS Connection code form
02
CCSWS Connection code style
0
CCTWS Connection code type
FLS
CCUWS Connection code unit base
9
CNSC Coolant entry style code
7 - Coolant entry, decentral and axially concentric
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0700
DCONWS Diameter
70 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2018
DIN
SKG05004795
FamilyProducts
SAH-2784950206
HAND Cutting direction
N - Neutral
ID Technical product number
02836708
Interface codes
J6 / J61
ISO
SKG47C0500$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LF Functional length
50 mm
LOC-01 CCFWS Connection code form
02
LOC-01 CCSWS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-01 CCTWS Connection code type
FLS Flange mounting Sandvik CDI
LOC-01 CCUWS Connection code unit base
9 non-dimensional size with coolant
LOC-01 CZCWS Connection size code
0700
LOC-01 DCONWS Diameter
70 mm
LOC-01 ISO
FLS02G7000$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
FLS07000290
LOC-02 DCONWS Diameter
70 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
SO-FLS070001M0
LOC-03 CCFMS Connection code form
47
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03 ISO
SKG47C0500$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05004795
Name Identifying order number
SAH-2784950206
OAL Overall length
151.8 mm
WT Weight of item
3.3 kg
