Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric M5260218

M5260218

M5260218 M5260218 M5260218 M5260218

M5260218

Seco
Артикул: 00096675
В наличии
В корзину
Описание
Характеристики
BD Body diameter
32 mm
BLQ Balance quality code
PB
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SWB
CCUWS Connection code unit base
0
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0190
DCONWS Diameter
19 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
GMS03200115
FamilyProducts
M5260218
HAND Cutting direction
N - Neutral
ID Technical product number
00096675
Interface codes
J6 / J61
ISO
GMS01G3200$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
27 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SWB Quick change adapter BILZ
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0190
LOC-01 DCONWS Diameter
19 mm
LOC-01 ISO
SWB01G1900$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SWB01900105
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
GMS Graflex modular connection SECO
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0320
LOC-03 ISO
GMS01G3200$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
GMS03200115
LPR Protruding length
40 mm
Name Identifying order number
M5260218
OAL Overall length
60 mm
WT Weight of item
0.21 kg
