Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric E934356722570

E934356722570

E934356722570 E934356722570 E934356722570 E934356722570

E934356722570

Seco
Артикул: 02827226
В наличии
В корзину
Описание
Характеристики
BD Body diameter
40 mm
BD Body diameter 2
40 mm
BLQ Balance quality code
G2.5
CCFWS Connection code form
14
CCSWS Connection code style
5
CCTWS Connection code type
SZD
CCUWS Connection code unit base
8
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0250
DCONWS Diameter
1 mm
DCONXWS Connection diameter max
16 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
HSK05000385
FamilyProducts
E934356722570
HAND Cutting direction
N - Neutral
ID Technical product number
02827226
Interface codes
J6 / J61
ISO
HSK03C0500$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
44 mm
LF Functional length
32 mm
LOC-01 CCFWS Connection code form
14
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SZD Collet adapter DIN / ISO
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0250
LOC-01 DCONWS Diameter
1 mm
LOC-01 DCONXWS Connection diameter max
16 mm
LOC-01 ISO
SZD14C0250$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SZD02501485
LOC-03 CCFMS Connection code form
03
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0500
LOC-03 ISO
HSK03C0500$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK05000385
LPR Protruding length
70 mm
Name Identifying order number
E934356722570
OAL Overall length
95 mm
WT Weight of item
0.67 kg
