Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric E930658406160

E930658406160

E930658406160 E930658406160 E930658406160 E930658406160

E930658406160

Seco
Артикул: 00034279
В наличии
В корзину
Описание
Характеристики
BD Body diameter
25 mm
BLQ Balance quality code
1
CCFWS Connection code form
10
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0060
DCONWS Diameter
6 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
6/7/2017
DIN
HSK10000185
FamilyProducts
E930658406160
HAND Cutting direction
N - Neutral
ID Technical product number
00034279
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LF Functional length
160 mm
LOC-01 CCFWS Connection code form
10
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CZCWS Connection size code
0060
LOC-01 DCONWS Diameter
6 mm
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
1000
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK10000185
LPR Protruding length
160 mm
LSCX Clamping length maximum
27 mm
Name Identifying order number
E930658406160
OAL Overall length
210 mm
WT Weight of item
2.37 kg
