Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric E93045525150237

E93045525150237

E93045525150237 E93045525150237 E93045525150237 E93045525150237

E93045525150237

Seco
Артикул: 02415445
В наличии
В корзину
Описание
Характеристики
BD Body diameter
88.9 mm
BLQ Balance quality code
G6.3
CCFWS Connection code form
02
CCSWS Connection code style
0
CCTWS Connection code type
FDA
CCUWS Connection code unit base
2
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
1500
DCONWS Diameter
38.1 mm
DCP Data chip provision
1 - With data chip
Delivery state valid from
3/14/2020
DIN
HSK06300185
FamilyProducts
E93045525150237
HAND Cutting direction
N - Neutral
ID Technical product number
02415445
Interface codes
J6 / J61
ISO
HSK01C0630$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
34.2 mm
LF Functional length
60.2 mm
LOC-01 CCFWS Connection code form
02
LOC-01 CCSWS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-01 CCTWS Connection code type
FDA Milling arbor mounting
LOC-01 CCUWS Connection code unit base
2 Inch
LOC-01 CZCWS Connection size code
1500
LOC-01 DCONWS Diameter
38.1 mm
LOC-01 ISO
FDA02S1500****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
FDA15000220
LOC-02 DCONWS Diameter
38.1 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
SO-FDA150022N0
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0630
LOC-03 ISO
HSK01C0630$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300185
LSCX Clamping length maximum
23.9 mm
Name Identifying order number
E93045525150237
OAL Overall length
116.1 mm
WT Weight of item
1.45 kg
