Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric E4041586725130

E4041586725130

E4041586725130 E4041586725130 E4041586725130 E4041586725130

E4041586725130

Seco
Артикул: 02926975
В наличии
В корзину
Описание
Характеристики
BD Body diameter
42 mm
BLQ Balance quality code
PB
CCFWS Connection code form
16
CCSWS Connection code style
5
CCTWS Connection code type
SZD
CCUWS Connection code unit base
8
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
0 - Without coolant exit
CZCWS Connection size code
0250
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
SKG04005185
DLN Diameter lock nut
44 mm
FamilyProducts
E4041586725130
HAND Cutting direction
N - Neutral
ID Technical product number
02926975
Interface codes
J6 / J61
ISO
SKG51C0400$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
37.1 mm
LOC-01 CCFWS Connection code form
16
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SZD Collet adapter DIN / ISO
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0250
LOC-01 ISO
SZD16C0250$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SZD02501685
LOC-03 CCFMS Connection code form
51
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0400
LOC-03 ISO
SKG51C0400$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04005185
LPR Protruding length
124.6 mm
Name Identifying order number
E4041586725130
OAL Overall length
190 mm
WT Weight of item
1.8 kg
