Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric E321658432105

E321658432105

E321658432105 E321658432105 E321658432105

E321658432105

Seco
Артикул: 02926048
В наличии
В корзину
Описание
Характеристики
BD Body diameter
72 mm
BLQ Balance quality code
PB
CCFWS Connection code form
10
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
1
CNSC Coolant entry style code
7 - Coolant entry, decentral and axially concentric
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0320
DCONWS Diameter
32 mm
DCP Data chip provision
1 - With data chip
Delivery state valid from
3/14/2020
DIN
SKG05005795
FamilyProducts
E321658432105
HAND Cutting direction
N - Neutral
ID Technical product number
02926048
Interface codes
J6 / J61
ISO
SKG57C0500$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
67 mm
LOC-01 CCFWS Connection code form
10
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0320
LOC-01 DCONWS Diameter
32 mm
LOC-01 ISO
ZYL10G3200****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL03201015
LOC-03 CCFMS Connection code form
57
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0500
LOC-03 ISO
SKG57C0500$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG05005795
LPR Protruding length
105 mm
LSCX Clamping length maximum
58 mm
Name Identifying order number
E321658432105
OAL Overall length
206.8 mm
WT Weight of item
5.3 kg
