Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric E2602582120135

E2602582120135

E2602582120135 E2602582120135 E2602582120135 E2602582120135

E2602582120135

Seco
Артикул: 03029746
В наличии
В корзину
Описание
Характеристики
BD Body diameter
37 mm
BLQ Balance quality code
G6.3
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SCM
CCUWS Connection code unit base
1
CNSC Coolant entry style code
7 - Coolant entry, decentral and axially concentric
COMPC Company code
SO - SECO Tools
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0365
DCINTF Interference cutting diameter
36.5 mm
DCP Data chip provision
1 - With data chip
Delivery state valid from
3/14/2020
DIN
SKG04003795
FamilyProducts
E2602582120135
HAND Cutting direction
N - Neutral
ID Technical product number
03029746
Interface codes
J6 / J61
ISO
SKG37C0400$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
20 mm
LB Length 2
112.9 mm
LB Length Body diameter 3
115.9 mm
LF Functional length
135 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SCM
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0365
LOC-01 ISO
SCM01G3650$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SCM03650115
LOC-03 CCFMS Connection code form
37
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SKG steep taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0400
LOC-03 ISO
SKG37C0400$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SKG04003795
LPR Protruding length
135 mm
Name Identifying order number
E2602582120135
OAL Overall length
203.4 mm
WT Weight of item
1.524 kg
