Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric C8-391.5675-32070

C8-391.5675-32070

C8-391.5675-32070 C8-391.5675-32070 C8-391.5675-32070 C8-391.5675-32070

C8-391.5675-32070

Seco
Артикул: 02750092
В наличии
В корзину
Описание
Характеристики
BD Body diameter
50 mm
BD Body diameter 2
50 mm
BLQ Balance quality code
G6.3
CCFWS Connection code form
02
CCSWS Connection code style
5
CCTWS Connection code type
SZD
CCUWS Connection code unit base
8
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0320
DCONWS Diameter
2 mm
DCONXWS Connection diameter max
20 mm
DCP Data chip provision
1 - With data chip
Delivery state valid from
3/14/2020
DIN
CCS08000185
FamilyProducts
C8-391.5675-32070
HAND Cutting direction
N - Neutral
ID Technical product number
02750092
Interface codes
J6 / J61
ISO
CCS01C0800$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
37 mm
LF Functional length
30 mm
LOC-01 CCFWS Connection code form
02
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SZD Collet adapter DIN / ISO
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0320
LOC-01 DCONWS Diameter
2 mm
LOC-01 DCONXWS Connection diameter max
20 mm
LOC-01 ISO
SZD02C0320$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SZD03200285
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
CCS Coromant Capto System SANDVIK
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0800
LOC-03 ISO
CCS01C0800$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS08000185
LPR Protruding length
70 mm
Name Identifying order number
C8-391.5675-32070
OAL Overall length
118 mm
WT Weight of item
2.058 kg
