Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric C8-391.0552-40035

C8-391.0552-40035

C8-391.0552-40035 C8-391.0552-40035 C8-391.0552-40035 C8-391.0552-40035

C8-391.0552-40035

Seco
Артикул: 02752405
В наличии
В корзину
Описание
Характеристики
BD Body diameter
70 mm
BLQ Balance quality code
G6.3
CCFWS Connection code form
02
CCSWS Connection code style
0
CCTWS Connection code type
FDA
CCUWS Connection code unit base
0
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0400
DCONWS Diameter
40 mm
DCP Data chip provision
1 - With data chip
Delivery state valid from
3/14/2020
DIN
CCS08000185
FamilyProducts
C8-391.0552-40035
HAND Cutting direction
N - Neutral
ID Technical product number
02752405
Interface codes
J6 / J61
ISO
CCS01C0800$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
2 mm
LF Functional length
35 mm
LOC-01 CCFWS Connection code form
02
LOC-01 CCSWS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-01 CCTWS Connection code type
FDA Milling arbor mounting
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0400
LOC-01 DCONWS Diameter
40 mm
LOC-01 ISO
FDA02G4000****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
FDA04000200
LOC-02 DCONWS Diameter
40 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
SO-FDA040002M0
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
CCS Coromant Capto System SANDVIK
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0800
LOC-03 ISO
CCS01C0800$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS08000185
LSCX Clamping length maximum
27 mm
Name Identifying order number
C8-391.0552-40035
OAL Overall length
110 mm
WT Weight of item
2.213 kg
