Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric C6-391.5835-12075

C6-391.5835-12075

C6-391.5835-12075 C6-391.5835-12075 C6-391.5835-12075 C6-391.5835-12075

C6-391.5835-12075

Seco
Артикул: 02881527
В наличии
В корзину
Описание
Характеристики
BD Body diameter
48 mm
BD Body diameter 2
63 mm
BLQ Balance quality code
PB
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
0
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0120
DCONWS Diameter
12 mm
DCP Data chip provision
1 - With data chip
Delivery state valid from
3/14/2020
DIN
CCS06300185
FamilyProducts
C6-391.5835-12075
HAND Cutting direction
N - Neutral
ID Technical product number
02881527
Interface codes
J6 / J61
ISO
CCS01C0630$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
38.5 mm
LF Functional length
38 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0120
LOC-01 DCONWS Diameter
12 mm
LOC-01 ISO
ZYL01G1200****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL01200105
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
CCS Coromant Capto System SANDVIK
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0630
LOC-03 ISO
CCS01C0630$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS06300185
LPR Protruding length
75 mm
Name Identifying order number
C6-391.5835-12075
OAL Overall length
113 mm
TA Taper angle
30 Degree
WT Weight of item
1.53 kg
