Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric C4-391.5603-037075

C4-391.5603-037075

C4-391.5603-037075 C4-391.5603-037075 C4-391.5603-037075

C4-391.5603-037075

Seco
Артикул: 02753419
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
2 - Axial adjustment possible
BD Body diameter
32 mm
BLQ Balance quality code
G6.3
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
ZYL
CCUWS Connection code unit base
2
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0375
DCINTF Interference cutting diameter
24 mm
DCONWS Diameter
9.525 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
CCS04000185
FamilyProducts
C4-391.5603-037075
HAND Cutting direction
N - Neutral
ID Technical product number
02753419
Interface codes
J6 / J61
ISO
CCS01C0400$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
55 mm
LF Functional length
44 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
ZYL cylindrical shank
LOC-01 CCUWS Connection code unit base
2 Inch
LOC-01 CZCWS Connection size code
0375
LOC-01 DCONWS Diameter
9.525 mm
LOC-01 ISO
ZYL01R3750****
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
ZYL03750125
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
CCS Coromant Capto System SANDVIK
LOC-03 CCUMS Connection code unit base
8 non-dimensional size
LOC-03 CZCMS Connection size code
0400
LOC-03 ISO
CCS01C0400$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
CCS04000185
LPR Protruding length
75 mm
LSCX Clamping length maximum
31 mm
Name Identifying order number
C4-391.5603-037075
OAL Overall length
99 mm
TA Taper angle
4.5 Degree
WT Weight of item
0.5 kg
