Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric BW519582210125

BW519582210125

BW519582210125 BW519582210125

BW519582210125

Seco
Артикул: 02454250
В наличии
В корзину
Описание
Характеристики
BLQ Balance quality code
PB
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SCM
CCUWS Connection code unit base
0
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0185
DCINTF Interference cutting diameter
18 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
ZYL07501025
FamilyProducts
BW519582210125
HAND Cutting direction
N - Neutral
ID Technical product number
02454250
Interface codes
J6 / J61
ISO
ZYL10R7500h$06
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
31.75 mm
LF Functional length
31.75 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SCM
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0185
LOC-01 ISO
SCM01G1850$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SCM01850105
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0750
LOC-03 ISO
ZYL10R7500h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL07501025
LPR Protruding length
31.75 mm
Name Identifying order number
BW519582210125
OAL Overall length
82.55 mm
TA Taper angle
30 Degree
WT Weight of item
0.16 kg
Диаметр корпуса (BD) / Body diameter (BD)
19.05 mm
