Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric BMH7004013660

BMH7004013660

BMH7004013660 BMH7004013660 BMH7004013660 BMH7004013660

BMH7004013660

Seco
Артикул: 02727669
В наличии
В корзину
Описание
Характеристики
BD Body diameter
70 mm
BLQ Balance quality code
PB
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
GMS
CCUWS Connection code unit base
1
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0630
DCINTF Interference cutting diameter
63 mm
DCONWS Diameter
40 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
HTS04000105
FamilyProducts
BMH7004013660
HAND Cutting direction
N - Neutral
ID Technical product number
02727669
Interface codes
J6 / J61
ISO
HTS01G4000$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LF Functional length
60 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
GMS Graflex modular connection SECO
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0630
LOC-01 DCONWS Diameter
40 mm
LOC-01 ISO
GMS01G6300$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
GMS06300115
LOC-02 DCONWS Diameter
40 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
SO-GMS006001M0
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HTS deep drilling system KENNAMETAL
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0400
LOC-03 ISO
HTS01G4000$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HTS04000105
Name Identifying order number
BMH7004013660
OAL Overall length
115 mm
WT Weight of item
1.64 kg
