Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric BMH5804013660

BMH5804013660

BMH5804013660 BMH5804013660 BMH5804013660 BMH5804013660

BMH5804013660

Seco
Артикул: 02727668
В наличии
В корзину
Описание
Характеристики
BD Body diameter
58 mm
BLQ Balance quality code
PB
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
GMS
CCUWS Connection code unit base
1
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0630
DCONWS Diameter
32 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
HTS03200105
FamilyProducts
BMH5804013660
HAND Cutting direction
N - Neutral
ID Technical product number
02727668
Interface codes
J6 / J61
ISO
HTS01G3200$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LF Functional length
60 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
GMS Graflex modular connection SECO
LOC-01 CCUWS Connection code unit base
1 Metric with coolant
LOC-01 CZCWS Connection size code
0630
LOC-01 DCONWS Diameter
32 mm
LOC-01 ISO
GMS01G6300$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
GMS06300115
LOC-02 DCONWS Diameter
32 mm
LOC-02-Connection-codes
J4 / J431 - Workpiece end
LOC-02-DIN
SO-GMS006001M0
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HTS deep drilling system KENNAMETAL
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0320
LOC-03 ISO
HTS01G3200$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HTS03200105
Name Identifying order number
BMH5804013660
OAL Overall length
110 mm
WT Weight of item
1.31 kg
