Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric BM06056754085

BM06056754085

BM06056754085 BM06056754085 BM06056754085 BM06056754085

BM06056754085

Seco
Артикул: 02750257
В наличии
В корзину
Описание
Характеристики
BD Body diameter
63 mm
BD Body diameter 2
63 mm
BLQ Balance quality code
PB
CCFWS Connection code form
02
CCSWS Connection code style
5
CCTWS Connection code type
SZD
CCUWS Connection code unit base
8
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0400
DCONWS Diameter
3 mm
DCONXWS Connection diameter max
26 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
GMS06300115
FamilyProducts
BM06056754085
HAND Cutting direction
N - Neutral
ID Technical product number
02750257
Interface codes
J6 / J61
ISO
GMS01G6300$$$$
ISYC Subclass
401-01 - Converter, rotationally symmetric
LF Functional length
35 mm
LOC-01 CCFWS Connection code form
02
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SZD Collet adapter DIN / ISO
LOC-01 CCUWS Connection code unit base
8 non-dimensional size
LOC-01 CZCWS Connection size code
0400
LOC-01 DCONWS Diameter
3 mm
LOC-01 DCONXWS Connection diameter max
26 mm
LOC-01 ISO
SZD02C0400$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SZD04000285
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
GMS Graflex modular connection SECO
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03 ISO
GMS01G6300$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
GMS06300115
LPR Protruding length
85 mm
Name Identifying order number
BM06056754085
OAL Overall length
125 mm
THSZWS Connection thread nominal size workpiece side
M12
WT Weight of item
1.73 kg
