Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric BD119582210300

BD119582210300

BD119582210300 BD119582210300 BD119582210300 BD119582210300

BD119582210300

Seco
Артикул: 02487324
В наличии
В корзину
Описание
Характеристики
BD Body diameter
18 mm
BLQ Balance quality code
PB
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SCM
CCUWS Connection code unit base
0
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0185
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
ZYL07500125
FamilyProducts
BD119582210300
HAND Cutting direction
N - Neutral
ID Technical product number
02487324
Interface codes
J6 / J61
ISO
ZYL01R7500h$05
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
76.2 mm
LF Functional length
76.2 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SCM
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0185
LOC-01 ISO
SCM01G1850$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SCM01850105
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0750
LOC-03 ISO
ZYL01R7500h$05
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL07500125
LPR Protruding length
76.2 mm
Name Identifying order number
BD119582210300
OAL Overall length
127 mm
TA Taper angle
30 Degree
WT Weight of item
0.254 kg
