Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric BD032582012100

BD032582012100

BD032582012100 BD032582012100 BD032582012100 BD032582012100

BD032582012100

Seco
Артикул: 02447657
В наличии
В корзину
Описание
Характеристики
BD Body diameter
24.7 mm
BD Body diameter 2
31 mm
BLQ Balance quality code
PB
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SCM
CCUWS Connection code unit base
0
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0230
DCINTF Interference cutting diameter
23 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
ZYL03200105
FamilyProducts
BD032582012100
HAND Cutting direction
N - Neutral
ID Technical product number
02447657
Interface codes
J6 / J61
ISO
ZYL01G3200h$05
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
25 mm
LF Functional length
100 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SCM
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0230
LOC-01 ISO
SCM01G2300$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SCM02300105
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0320
LOC-03 ISO
ZYL01G3200h$05
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03200105
LPR Protruding length
100 mm
Name Identifying order number
BD032582012100
OAL Overall length
160 mm
TA Taper angle
4.5 Degree
WT Weight of item
0.822 kg
