Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric BD01858221070

BD01858221070

BD01858221070 BD01858221070 BD01858221070 BD01858221070

BD01858221070

Seco
Артикул: 02447686
В наличии
В корзину
Описание
Характеристики
BLQ Balance quality code
PB
CCFWS Connection code form
01
CCSWS Connection code style
5
CCTWS Connection code type
SCM
CCUWS Connection code unit base
0
COMPC Company code
SO - SECO Tools
CZCWS Connection size code
0185
DCP Data chip provision
0 - Without data chip
Delivery state valid from
3/14/2020
DIN
ZYL01800105
FamilyProducts
BD01858221070
HAND Cutting direction
N - Neutral
ID Technical product number
02447686
Interface codes
J6 / J61
ISO
ZYL01G1800h$05
ISYC Subclass
401-01 - Converter, rotationally symmetric
LB Body length 1
70 mm
LF Functional length
70 mm
LOC-01 CCFWS Connection code form
01
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SCM
LOC-01 CCUWS Connection code unit base
0 Metric
LOC-01 CZCWS Connection size code
0185
LOC-01 ISO
SCM01G1850$$$$
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SCM01850105
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0180
LOC-03 ISO
ZYL01G1800h$05
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01800105
LPR Protruding length
70 mm
Name Identifying order number
BD01858221070
OAL Overall length
118 mm
TA Taper angle
30 Degree
WT Weight of item
0.203 kg
Диаметр корпуса (BD) / Body diameter (BD)
18 mm
