Главная Каталог продукции Toolunited 17 401-01 - Converter, rotationally symmetric 7801918

7801918

7801918

7801918

OSG
Артикул: 7801918
В наличии
В корзину
Описание
Характеристики
A2 CHA Chamfer angle at length 2
16.773 Degree
A2 CHW Chamfer width at length 2
1.659 mm
ADJBY Adjustment property
0 - Adjustment not possible
BD Body diameter
9 mm
BD Body diameter 2
10 mm
CCFWS Connection code form
02
CCSWS Connection code style
5
CCTWS Connection code type
SAO
CCUWS Connection code unit base
9
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
OSG
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
CZCWS Connection size code
0060
DCP Data chip provision
0 - Without data chip
DIN
ZYL01000115
FamilyProducts
OSG OP-SFA-Carb -J SF-M06SS10-24CS
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
401-01 - Converter, rotationally symmetric
LAM Actuation method
0 - manual clamping
LB Body length 1
22.341 mm
LOC-01 CCFWS Connection code form
02
LOC-01 CCSWS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-01 CCTWS Connection code type
SAO Screw mounting OSG
LOC-01 CCUWS Connection code unit base
9 non-dimensional size with coolant
LOC-01 CZCWS Connection size code
0060
LOC-01-Connection-codes
J4 / J431 - Workpiece end
LOC-01-DIN
SAO00600295
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0100
LOC-03 DCONMS Diameter
10 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01000115
LPR Protruding length
24 mm
LS Shank length
100 mm
Name Identifying order number
7801918
OAL Overall length
124 mm
