Главная Каталог продукции Toolunited 17 303-06 - Ball-nosed end mill VR.UN.L236.0600.OL.Z2.R0300.HA SCPP225L

VR.UN.L236.0600.OL.Z2.R0300.HA SCPP225L

Артикул: WL236060440

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

10 mm

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

CE - Ceratizit

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

6 mm

DCP Data chip provision

0 - Without data chip

DIN

ZYL00600105

FamilyProducts

Mini-Schaftfräser WL236-OL

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GAMF Rake angle radial

30 Degree

GAMP Rake angle axial

13 Degree

GRDMFG Grade manufacturers designation

SCPP225L

GRDPRIO Standard designation of the grade main application

HC-P25

HAND Cutting direction

R - Right

ID Technical product number

WL236060440

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$05

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600105

Name Identifying order number

VR.UN.L236.0600.OL.Z2.R0300.HA SCPP225L

OAL Overall length

100 mm

PRFRAD Profile radius 1

3 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FFO - Die milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
