Главная Каталог продукции Toolunited 17 303-06 - Ball-nosed end mill UJBE0375J6AL KCSM15

UJBE0375J6AL KCSM15

Артикул: 5607300

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

12.7 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

9.525 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

8/27/2014

DIN

ZYL03750125

DN Neck diameter

8.9535 mm

FamilyProducts

HARVI III 6F BN 0,375X0,375X0,5-2X6

FHA Flute helix angle

38 Degree

GRDMFG Grade manufacturers designation

KCSM15

HAND Cutting direction

R - Right

ID Technical product number

5607300

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

2 Inch

LOC-03 CZCMS Connection size code

0375

LOC-03 DCONMS Diameter

9.525 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

H$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03750125

LS Shank length

101.3155 mm

MILTTY Mill tool type ISO

E - Disc mill - one side cutting

Name Identifying order number

UJBE0375J6AL KCSM15

OAL Overall length

152.4 mm

PRFRAD Profile radius 1

4.7625 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FEC - Square shoulder milling,FFO - Die milling,FNU - Groove milling,FPL - Face milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
