Главная Каталог продукции Toolunited 17 303-06 - Ball-nosed end mill MRO.V.0837.0400.L.Z4.R0200.HA SCPX215

MRO.V.0837.0400.L.Z4.R0200.HA SCPX215

Артикул: W0837040370

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

16 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

DLC

COMPC Company code

CE - Ceratizit

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

4 mm

DCP Data chip provision

0 - Without data chip

DIN

ZYL00600105

FamilyProducts

Multiple milling cutters for plastics W0837-L

GRDMFG Grade manufacturers designation

SCPX215

GRDPRIO Standard designation of the grade main application

HC-N15

HAND Cutting direction

R - Right

ID Technical product number

W0837040370

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00600105

Name Identifying order number

MRO.V.0837.0400.L.Z4.R0200.HA SCPX215

OAL Overall length

57 mm

PRFRAD Profile radius 1

2 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FFO - Die milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
